July 2009

OA research: It’s all about the shoes

Laterally wedged orthoses are effective to a point, but the next big thing in knee osteoarthritis treatment just might be a prototype shoe with a sole that notable for its variable stiffness rather than its slope.

grandfather and grandaughter walking

iStockphoto.com/Gary Sludden

Osteoarthritis (OA) of the knee is a degenerative joint disease that afflicts approximately 30% of Americans over the age of 65.1,2 The medial compartment of the knee the most commonly affected area of the joint.3,4 The high prevalence of medial compartment knee OA is due in part to the high percentage of loading transmitted across the medial aspect of the knee, approximately 60% to 80% of the total load.5-7 Knee OA is associated with pain and major limitations in a patient’s mobility, and thus may not only restrict a patient’s activities of daily living but may also have a major impact on his or her social life and psychological health.8 The prevalence of the disease is only expected to increase in the coming years as the baby-boomer generation ages, and it is anticipated that by 2030 more than 20% of the American population will be over the age of 65 and at risk of developing this debilitating disease.9

Current therapies for knee OA aim to attenuate pain, improve function, and reduce the risk of further joint deterioration, while minimizing adverse effects of treatment.10 Surgical interventions, including high tibial osteotomy and total knee arthroplasty, are often reserved for advanced cases. High tibial osteotomy realigns the static position of the knee to alter load distribution,11,12 and, although often effective in reducing loads on the medial compartment, is a highly invasive procedure with a long recovery period and associated complications including deep vein thrombosis, infection, technical complications, and nonunion requiring further surgery.13 Total knee replacement is an effective medical intervention that can relieve pain and disability of end-stage osteoarthritis. However, this procedure is highly invasive, is reserved for severe cases, and has limited durability in patients who are likely to outlive their implants (which last approximately 20 years) or those who wish to resume demanding activities.10 In earlier stages of the disease when non-surgical treatments are desirable, drug therapies may be used. Pharmacologic treatment, though effective in reducing pain, does not stop the degenerative disease process of OA, and is also associated with adverse effects including gastrointestinal or renal toxicity.14 There is a clear need for effective non-invasive treatment of knee OA without the potential harmful side-effects of drug therapies.

Figure 1: Intervention shoe used in the study. The shoe sole was approximately 1.3-1.5 times stiffer on the lateral aspect than the medial aspect, with the medial aspect of the shoe similar to the control (C) shoe sole stiffness.

Figure 1: Intervention shoe used in the study. The shoe sole was approximately 1.3-1.5 times stiffer on the lateral aspect than the medial aspect, with the medial aspect of the shoe similar to the control (C) shoe sole stiffness.

An important parameter to consider in joint deterioration in knee OA is the knee adduction moment.7 In healthy individuals, the load transferred through the medial compartment of the knee during walking is nearly 2.5 times greater than the load transferred through the lateral compartment.7 Analytical methods have shown that an increase in the medial compartment joint loading is related to an increase in the peak external adduction moment about the knee.7,15,16 This peak knee adduction moment has been associated with the severity, rate of progression, and treatment outcome of medial compartment knee osteoarthritis.17-19 Reducing the knee adduction moment, therefore, is a key objective of new treatments designed to slow the progression of knee OA.

Offloading options
Conservative treatments studied for knee OA have included unloader braces, laterally-wedged insoles, and footwear. Valgus bracing is used to reduce the load on the medial compartment of the knee by application of an opposing external valgus moment about the knee joint.20 Valgus bracing has been found to reduce the knee adduction moment in patients with medial compartment knee OA by approximately 12%.20,21 Several studies have also investigated clinical results, and found improvements in both pain relief and physical function with the use of bracing.22,23 However, the studies also found that many patients do not adhere to bracing treatment in the long term. In one study, more than 40% of patients assigned to the bracing intervention discontinued brace use after one year, with the main reasons being no effect of treatment, skin irritation, and poor fit.22 A review of custom-fitted load-shifting braces also found a 24% failure rate after one year of treatment, increasing to nearly a 40% failure rate after three years of treatment, with failures including reluctance to use the brace due to bulk and inconvenience, leg swelling, skin irritation, and pulmonary embolus.24 Thus, the side effects of braces may limit their applicability and must be weighed when considering long-term patient use.

Sasaki and Yasuda first reported the potential of a laterally-wedged insole to reduce medial compartment knee joint loading.25,26 More recent studies of lateral wedging in both healthy15,27 and osteoarthritic28-32 subjects have reported varying results in adduction moment reduction. In healthy subjects, a study of 5o wedges found reductions in average peak knee adduction moment of approximately 7%.15 However, another study in a healthy population found reductions in the adduction moment only when using a rigid ankle-foot-orthosis in combination with a lateral wedge, and not with a lateral wedge alone.27 In an osteoarthritic population28 a 5o lateral wedge failed to produce reductions in peak knee adduction moment. Another study reported reductions in the adduction moment of 6% with a 5o lateral wedge and 8% with a more severe 10o lateral wedge.29 However, the more severe lateral wedges were associated with discomfort, which may limit their long-term clinical applicability.29,33

Figure 2: Depiction of the difference in stiffness between the lateral (stiffer) and medial (less stiff) aspects of the variable-stiffness intervention shoe sole.

Figure 2: Depiction of the difference in stiffness between the lateral (stiffer) and medial (less stiff) aspects of the variable-stiffness intervention shoe sole.

The clinical efficacy of lateral wedges also remains unclear. There have been mixed reports on improvement in pain and function with use of lateral wedges. Several studies have found improvements when using wedges and analgesics compared analgesics alone25,34 or when only investigating the effect of the lateral wedge in osteoarthritic subjects.33,35 However, several more recent studies comparing lateral-wedged insoles with neutral insoles failed to find significant differences between the two  conditions with regard to reduced pain.36-38

Gotta be the shoes
The limited clinical success of wedges and braces led to the investigation of a novel load-modifying shoe intervention for treatment of medial compartment OA of the knee. The variable-stiffness shoe is a normally-appearing athletic shoe (Figures 1,2) with a sole that is not wedged but has been custom-designed so that the lateral aspect has greater stiffness than the medial aspect. By comparison, conventional motion-control athletic shoes may have soles of varying stiffness, but such that the medial aspect is stiffer than the lateral aspect; neutral-cushion athletic shoes and conventional dress shoes typically have constant-stiffness soles.

The variable-stiffness sole of the test shoe is made of compression molded ethylene vinyl acetate, and the lateral sole (Asker C durometer 55 ± 2) is 1.3-1.5 times stiffer than the medial sole (Asker C durometer 70-76 ± 2). The shoe design was first tested in a healthy cohort.39 Results from the study were promising, reporting an average reduction in the peak knee adduction moment during gait of approximately 7% without reports of subject discomfort.39 The findings in the healthy population spurred investigation of the shoe design in the target population, individuals with medial compartment knee osteoarthritis.

A one-year prospective randomized control study was used to compare the effects of the variable-stiffness intervention footwear with constant-stiffness control footwear in an osteoarthritic population. Seventy-nine individuals (42 male and 37 female; average age: 60 ± 10 years) with symptoms of medial compartment knee OA participated in the study after giving written consent in accordance with the Institutional Review Board. Subject enrollment criteria are given in Table 1. At a baseline visit, subjects were randomly and blindly assigned to either the variable-stiffness intervention shoe or the constant-stiffness placebo control shoe to wear as their main walking shoe for 12 months (defined as at least four hours of wear per day).  The subjects were encouraged to wear the shoe as much as possible.

Figure 3: Absolute reductions in peak knee adduction moment with the intervention shoe versus the control shoe at slow, normal, and fast walking speeds for all subjects (n=79) at the baseline gait test. * = significant reduction at p<0.01.

Figure 3: Absolute reductions in peak knee adduction moment with the intervention shoe versus the control shoe at slow, normal, and fast walking speeds for all subjects (n=79) at the baseline gait test. * = significant reduction at p<0.01.

The overall goal of the study was to evaluate the effectiveness of variable-stiffness shoes in treatment of subjects with symptoms of medial compartment knee osteoarthritis. Specifically, the study aimed to understand (1) the effects of the variable-stiffness shoes on immediate and long-term changes in peak knee adduction moment compared to a constant-stiffness control shoe and (2) the effects of the variable-stiffness shoes on pain and function after long-term wear.

Knee loading results
Gait analysis was performed at the baseline test using a method previously described41 to assess joint loading of the subjects’ more symptomatic leg. As reported earlier,40 at the baseline gait test the peak knee adduction moment was significantly lower in the variable-stiffness intervention shoe than in the constant-stiffness control shoe at slow, normal, and fast walking speeds (Figure 3; p<0.01). The average between-condition difference in knee adduction moment increased significantly (p<0.001) with increasing walking speed, from 2.4% (p<0.01) at the slow speed, to 5.7% at normal speed (p<0.001), and 6.2% at the fast speed (p<0.001).

The magnitude of change in the peak knee adduction moment with the intervention shoe, however, varied among patients. While the majority of patients (more than 80%) had reductions in adduction moment with the intervention shoe compared to the control shoe at the baseline gait test, the change in peak knee adduction moment  ranged from more than a 20% reduction to a 7% increase at the normal walking speed.40 Importantly, reductions in the knee adduction moment at this baseline test occurred without overloading of other lower extremity joints, with secondary changes in frontal plane moments at the hip, knee, and ankle primarily showing reductions.40

The reductions in knee adduction moment seen in this study are in good agreement with reductions of approximately 5% to 6% reported using 5o and 6o laterally-wedged insoles.29,31 The reductions are less than those reported following high tibial osteotomy, where reductions in the knee adduction moment have been reported to range from approximately 19%42 to 30%11. However, given the invasiveness of high tibial osteotomy, as well as the associated complications,13 the variable-stiffness shoe may provide a suitable early intervention for patients with earlier-stage medial compartment knee OA, before surgical procedures are necessary. A 2002 study by Miyazaki et al.17 found that the risk of progression of medial compartment knee osteoarthritis increases more than six-fold with a one-unit increase in the knee adduction moment. Thus, reductions found in this study may be large enough to slow the progression of the disease.

The increase in reduction in the knee adduction moment with increasing speed may suggest that at faster speeds, greater forces are placed upon the variable-stiffness shoe, causing a greater differential displacement in the shoe sole. The intervention shoe may therefore be thought of as a dynamic lateral wedge.40 The magnitude of the change in adduction moment with the intervention shoe at the baseline gait test did vary substantially among subjects, and future research is needed to examine subject specific characteristics, such as disease severity, which may affect patient response to the shoe.42 Subject specific shoe stiffness variations may improve reductions in adduction moment, and could be considered in a future design iteration.

The baseline testing results are promising, suggesting that the intervention shoe may be an effective non-invasive treatment for medial compartment knee OA. Testing after six and 12 months of shoe wear also demonstrates that the reduction in adduction moment with the intervention shoe is maintained.42-45 These results are important, as they demonstrate that the intervention shoe is suitable for long-term use to reduce loading on the affected compartment of the knee joint.

Pain and function outcomes
To assess pain and physical function at the baseline test and after six and 12 months of shoe wear, the Western Ontario and McMaster Universities Osteoarthritis Index (WOMAC) was used.46 The WOMAC consists of five questions on pain, two questions about joint stiffness, and 17 questions about function. A low score indicates little pain/best function; a high score indicates more pain/worse function.

At the six month time point, significant reductions in total WOMAC score (indicating improvements in pain and function) were seen for the intervention group, but not for the group wearing the control shoe.44 At the 12 month time point, reductions in total WOMAC score for the intervention group continued, indicating sustained improvements in pain and function, while the control group had no significant improvements in pain or function.43 Furthermore, analysis by disease severity suggested that the intervention shoe may have the greatest effect on pain, function and knee adduction moment in patients with early medial compartment knee OA.42

Conclusion

The results of this study suggest that alterations in the properties of the sole material of a shoe can reduce a specific aspect of joint loading related to increased risk of OA progression. The improvements in pain and function, in combination with the reduction in knee adduction moment, suggest the variable-stiffness intervention shoes may be an inexpensive, low-risk treatment for medial compartment knee osteoarthritis.  This intervention may have broad applicability to delay the onset or slow the progression of this debilitating disease, allowing osteoarthritis patients to remain active even as they age

Jennifer C. Erhart, PhD, is a post-doctoral fellow at the Stanford University Biomotion Laboratory in the department of mechanical engineering.

Nicholas J. Giori, MD, PhD, is chief of orthopedic surgery and acting co-director of the Bone and Joint Rehabilitation Research and Development Center at the VA Palo Alto Healthcare System, and an assistant professor of orthopedic surgery and mechanical engineering at Stanford University.

Thomas P. Andriacchi, PhD is a professor of mechanical engineering and orthopedic surgery at Stanford University and acting co-director of the Bone and Joint Rehabilitation Research and Development Center at the VA Palo Alto Healthcare System.

None of the authors had any conflicts of interest regarding this manuscript.

Acknowledgements

This work was supported by the Veterans Administration (VA A02-2577R).  The authors would like to thank Chris Dyrby, Anne Mündermann, and Barbara Elspas for assistance in data collection and valuable feedback on this project, and Nike Inc. for providing the intervention shoes used in this study.

References

  1. Felson DT, Naimark A, Anderson J, et al. The prevalence of knee osteoarthritis in the elderly. The Framingham Osteoarthritis Study. Arthritis Rheum 1987;30(8):914-918.
  2. Breedveld FC. Osteoarthritis – the impact of a serious disease. Rheumatology 2004;43(suppl):i4-i8.
  3. Ahlback S. Osteoarthrosis of the knee. A radiographic investigation. Acta Radiol Diagn (Stockholm) 1968;277(suppl):7-72.
  4. Thomas RH, Resnick D, Alazraki NP, et al. Compartmental evaluation of osteoarthritis of the knee: A comparative study of available diagnostic modalities. Radiology 1975;116(3):585–594.
  5. Johnson F, Leitl S, Waugh W. The distribution of load across the knee: A comparison of static and dynamic measurements. J Bone Joint Surg 1980;62(3):346-349.
  6. Andriacchi TP: Dynamics of knee malalignment. Orthop Clin North Am 1994;25(3):395-403.
  7. Schipplein OD, Andriacchi TP. Interaction between active and passive knee stabilizers during level walking. J Orthop Res 1991;9(1):113-119.
  8. Guccione AA, Felson DT, Anderson JJ, et al. The effects of specific medical conditions on the functional limitations of elders in the Framingham Study.  Am J Public Health 1994;84(3):351-358.
  9. Elders MJ. The increasing impact of arthritis on public health.  J Rheumatol  2000;27(suppl):6-8.
  10. Felson DT. Osteoarthritis: New insights: Part 2: Treatment approaches. Ann Intern Med 2000;133(9):726-737.
  11. Prodromos CC, Andriacchi TP, Galante JO. A relationship between gait and clinical changes following high tibial osteotomy. J Bone Joint Surg Am 1985;67(8):1188-1194.
  12. Wang JW, Kuo KN, Andriacchi TP, Galante JO. The influence of walking mechanics and time on the results of proximal tibial osteotomy.  J Bone Joint Surg Am 1990;72(6):905-909.
  13. Magyar G, Toksvig-Larsen S, Lindstrand A. Hemicallotasis open-wedge osteotomy for osteoarthritis of the knee. Complications in 308 operations. J Bone Joint Surg Br1999;81(3):449-451.
  14. Lazzaroni M, Bianchi Porro G. Gastrointestinal side-effects of traditional non-steroidal anti-inflammatory drugs and new formulations. Ailment Pharmacol Ther 2004;20(suppl 2):48-58.
  15. Crenshaw SJ, Pollo FE, Calton EF. Effects of lateral-wedged insoles on kinetics at the knee. Clin Othop 2000;375:185-192.
  16. Zhao D, Banks SA, Mitchell KH, et al. Correlation between the knee adduction torque and medial contact force for a variety of gait patterns. J Orthop Res 2007;25(6):789-797.
  17. Miyazaki T, Wada M, Kawahara H, et al. Dynamic load at baseline can predict radiographic disease progression in medial compartment knee osteoarthritis. Ann Rheum Dis 2002;61(7):617-622.
  18. Mündermann A, Dyrby CO, Hurwitz DE, et al. Potential strategies to reduce medial compartment loading in patients with knee osteoarthritis of varying severity: reduced walking speed. Arthritis Rheum 2004;50(4):1172-1178.
  19. Sharma L, Hurwitz DE, Thonar EJ, et al. Knee adduction moment, serum hyaluronan level, and disease severity in medial tibiofemoral osteoarthritis. Arthritis Rheum 1998;41(7):1233-1240.
  20. Pollo FE, Otis JC, Backus SI, et al. Reduction of medial compartment loads with valgus bracing of the osteoarthritic knee. Am J Sports Med 2002;30(3):414-421.
  21. Self BP, Greenwald RM, Pflaster DS. A biomechanical analysis of a medial unloading brace for osteoarthritis of the knee.  Arthritis Care Res 2000;13(4):191-197.
  22. Brouwer RW, van Raaij TM, Verhaar JA, et al. Brace treatment for osteoarthritis of the knee: a prospective randomized multi-centre trial. Osteoarthritis Cartilage 2006;14(8):777-783.
  23. Draganich L, Reider B, Rimington T, et al. The effectiveness of self-adjustable custom and off-the-shelf bracing in the treatment of varus gonarthrosis.  J Bone Joint Surg Am 2006;88(12):2645-2652.
  24. Giori NJ. Load-shifting brace treatment for osteoarthritis of the knee: a minimum 2 1/2-year follow-up study. J Rehabil Res Dev 2004;41(2):187-194.
  25. Sasaki T, Yasuda K. Clinical evaluation of the treatment of osteoarthritic knees using a newly designed wedged insole. Clin Orthop Relat Res 1987;(221):181-187.
  26. Yasuda K, Sasaki T. The mechanics of treatment of the osteoarthritic knee with a wedged insole. Clin Orthop Relat Res 1987;(215):162-172.
    Schmalz T, Blumentritt S, Drewitz H, Freslier M. The influence of sole wedges on frontal plane knee kinetics, in isolation and in combination with representative rigid and semi-rigid ankle-foot-orthoses. Clin Biomech 2006;21(6):631-639.
  27. Maly MR, Culham EG, Costigan PA. Static and dynamic biomechanics of foot orthoses in people with medial compartment knee osteoarthritis. Clin Biomech 2002;17(8):603-610.
  28. Kerrigan DC, Lelas JL, Goggins J, et al. Effectiveness of a lateral-wedge insole on knee varus torque in patients with knee osteoarthritis. Arch Phys Med Rehabil 2002;83(7):889-893.
  29. Kakihana W, Akai M, Nakazawa K, et al. Inconsistent knee varus moment reduction caused by a lateral wedge in knee osteoarthritis. Am J Phys Med Rehabil 2007;86(6):446-454.
  30. Kakihana W, Akai M, Nakazawa K, et al. Effects of laterally wedged insoles on knee and subtalar joint moments. Arch Phys Med Rehabil 2005;86(7):1465-1471.
  31. Butler RJ, Marchesi S, Royer T, Davis IS. The effect of a subject-specific amount of lateral wedge on knee mechanics in patients with medial knee osteoarthritis. J Orthop Res 2007;25(9):1121-1127.
  32. Toda Y, Tsukimura N. A six-month follow-up of a randomized trial comparing the efficacy of a lateral-wedge insole with subtalar strapping and an in-shoe lateral-wedge insole in patients with varus deformity osteoarthritis of the knee. Arthritis Rheum 2004;50(10):3129-3136.
  33. Tohyama H, Yasuda K, Kaneda K. Treatment of osteoarthritis of the knee with heel wedges. Int Orthop 1991;15(1):31-33.
  34. Rubin R, Menz HB. Use of laterally wedged custom foot orthoses to reduce pain associated with medial knee osteoarthritis: a preliminary investigation. J Am Podiatr Med Assoc 2005;95(4):347-352.
  35. Baker K, Goggins J, Xie H, et al. A randomized crossover trial of a wedged insole for treatment of knee osteoarthritis. Arthritis Rheum 2007;56(4):1198-1203.
  36. Pham T, Maillefert JF, Hudry C, et al. Laterally elevated wedged insoles in the treatment of medial knee osteoarthritis. A two-year prospective randomized controlled study. Osteoarthritis Cartilage 2004;12(1):46-55.
  37. Barrios JA, Crenshaw JR, Royer TD, Davis IS. Walking shoes and laterally wedged orthoses in the clinical management of medial tibiofemoral osteoarthritis: A one-year prospective controlled trial. Knee 2009;16(2):136-142.
  38. Fisher DS, Dyrby CO, Mündermann A, et al. In healthy subjects without knee osteoarthritis, the peak knee adduction moment influences the acute effect of shoe interventions designed to reduce medial compartment knee load. J Orthop Res 2007;25(4):540-546.
  39. Erhart JC, Mündermann A, Elspas B, et al. A variable-stiffness shoe lowers the knee adduction moment in subjects with symptoms of medial compartment knee osteoarthritis. J Biomech 2008;41(12):2720-2725.
  40. Wada M, Imura S, Nagatani K, Baba H, Shimada S, Sasaki S. Relationship between gait and clinical results after high tibial osteotomy. Clin Orthop Relat  Res 1998;(354):180–188.
  41. Erhart JC, Giori NJ, Andriacchi TP. Disease severity influences patient response for variable-stiffness walking shoe after one year of wear. Presented at North American Congress on Biomechanics, Ann Arbor, MI, August 2008.
  42. Erhart JC, Giori NJ, Andriacchi  TP. Variable-stiffness walking shoe lowers knee adduction moment, reduces pain, and improves function in patients with osteoarthritis after one year.  Presented at 54th annual meeting of the Orthopaedic Research Society, San Francisco, CA, March 2008.
  43. Erhart JC, Giori NJ, Andriacchi TP. Load-modifying footwear intervention lowers knee adduction moment, reduces pain, and improves function in subjects with medial compartment knee osteoarthritis. Presented at 31st annual meeting of the American Society of Biomechanics, Stanford, CA, August 2007.
  44. Erhart JC, Dyrby CO, Elspas B, et al. Short and long-term reductions in knee  adduction moment in patients with medial compartment knee osteoarthritis with a variable-stiffness walking shoe. Presented at 53rd annual meeting of the Orthopaedic Research Society, San Diego, CA, February 2007.
  45. Bellamy N. Outcome measurement in osteoarthritis clinical trials. J Rheumatol Suppl 1995;43:49-51.

Table 1:  Subject inclusion and exclusion criteria

Inclusion Criteria

  • Persistent medial compartment knee joint pain
  • Ambulatory without aids. Between 40 and 80 years of age
  • Ability to give informed consent

Exclusion Criteria

  • Nerve or muscle disease associated with walking difficulty
  • Serious injury to foot, ankle, back, or hips. Use of shoe insert or hinged knee brace
  • Gout or recurrent pseudogout
  • Total knee replacement
  • Narcotic pain medication use
  • Intraarticular joint injection in previous 2 months
  • Body Mass Index (BMI) > 35 kg/m2
  • Diagnosed or symptomatic osteoarthritis in other lower extremity joints
  • Inability to have an MRI scan
